LED KLS-120 Compact Light Set
Affordable starter system
The KLS-120 represents a very affordable entry into the world of compact lighting systems. Nevertheless, it features 12 ultra-modern LEDs and RGBW color mixing.
Equipment
The power is supplied via an IEC power socket and can also be passed on to other devices via a corresponding IEC output socket. And the QuickDMX USB socket for wireless DMX operation has not been omitted either.
Transport and assembly
The unit is supplied in a convenient carrying bag. The system can be mounted on a standard speaker stand via a tripod sleeve; however, thanks to the integrated rubber feet, the bar can also be placed directly on the floor.
Compact Light Set with 4 RGBW Spots
- Crossbar with integrated DMX control unit and stand sleeve
- Ultra-light ideally suited for mobile use
- Ideal for bands, stages or solo entertainers
- Suited for installation on a speaker stand (not included) or truss
- Comes pre-assembled with practical transport bag
- 3 powerful 4in1 LEDs per spot provide for an exquisite RGBW color mix
- Movable and tiltable spotlights
- Via DMX, each spot can be individually controlled
- DMX-controlled operation or stand-alone operation with Master/Slave function
- Supports QuickDMX - the wireless DMX-system from Eurolite
- Built-in phantom fed socket for QuickDMX receiver (see accessories)
- Functions: RGBW color mixture, color presets, built-in programs, strobe effects with variable speed, dimmer, Master/Slave operation
- Addressing and setting via control panel with 4-digit LED display
- Additional controlling possibility via the EUROLITE IR-7 remote control, included in delivery
- Black lacquered metal version with movable mounting bracket
- IEC terminals for power linking up to 8 units
- LED: 12 x high-power 8 W 4in1 QCL RGBW (homogenous color mix)
- Can be operated in 4; 7; 16; 19 CH mode
- The device is cooled by passive convection
- Controlling by Stand-alone; DMX; IR remote control; Master/slave function; Sound to light via Microphone; QuickDMX via USB (optional)
- Is in EASY SHOW; LED EASY OPERATOR DELUXE already preprogrammed
- Flicker-free projection
| Power supply: |
100-240 V AC, 50/60 Hz |
| Power consumption: |
30 W |
| IP classification: |
IP20 |
| Power connection: |
Mains input IEC connector (M) mounting version Power supply cord with safety plug |
| Power output: |
IEC connector (F) mounting version |
| Fuse: |
T 1 A Fuse replaceable |
| Lamp type: |
LED lamp |
| LED: |
12 x high-power 8 W 4in1 QCL RGBW (homogenous color mix) |
| Flash rate: |
0 - 20 Hz |
| DMX channels: |
4; 7; 16; 19 |
| DMX input: |
3-pin XLR (M) mounting version |
| DMX output: |
3-pin XLR (F) mounting version |
| Cooling: |
Passive convection |
| Control: |
Stand-alone; DMX; IR remote control; Master/slave function; Sound to light via Microphone; QuickDMX via USB (optional); EASY SHOW; LED EASY OPERATOR DELUXE |
| Beam angle: |
18° |
| Beam angle (1/2 peak): |
18° |
| Beam angle (1/10 peak): |
34° |
| Housing color: |
Black |
| Attachment system: |
Ø 35mm |
| Display type: |
4 digits 7-segment LED display |
| Dimensions: |
Width: 61,6 cm
Depth: 10,0 cm
Height: 22,6 cm |
| Weight: |
3,70 kg |
