LED bar (60 cm) with 6 x 4 W 4in1 LED (RGBA)
- Operable in stand-alone mode or via DMX
- Microphone sensitivity adjustable via Control Board
- Supports QuickDMX - the wireless DMX system from Eurolite
- Built-in phantom-powered USB port for QuickDMX receivers (accessories)
- Comfortable addressing and setting via control board with LED display and four operating buttons
- Functions: Static colors, RGBA color blend, color temperature settings, internal programs, dimmer and strobe settings, Master/Slave
- Equipped with 6 x 4 W QCL LED in the colors red, green, blue and amber
- Hanging as well as standing installation possible
- Locking possibility at the mounting bracket
- IEC terminals for power linking up to 8 units
- Switch-mode power supply for operation between 100 and 240 volts
- LED: 6 x high-power 4 W 4in1 QCL RGBA (homogenous color mix)
- Can be operated in 2; 4; 5; 6; 9 CH mode
- The device is cooled by passive convection
- Controlling by Stand-alone; DMX; Sound to light via Microphone; QuickDMX via USB (optional)
- Is in EUROLITE LED PC-Control 512 software already preprogrammed
- Flicker-free projection
- Effect: Strobe effect
Power supply: |
100-240 V AC, 50/60 Hz |
Power consumption: |
15 W |
IP classification: |
IP20 |
Power connection: |
Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided) |
Power output: |
1 x IEC connector (F) mounting version |
Lamp type: |
LED lamp |
LED: |
6 x high-power 4 W 4in1 QCL RGBA (homogenous color mix) |
Flash rate: |
0 - 20 Hz |
DMX channels: |
2; 4; 5; 6; 9 |
DMX input: |
1 x 3-pin XLR (M) mounting version |
DMX output: |
1 x 3-pin XLR (F) mounting version |
Cooling: |
Passive convection |
Control: |
Stand-alone; DMX; Sound to light via Microphone; QuickDMX via USB (optional); EUROLITE LED PC-Control 512 software |
Beam angle: |
17° |
Beam angle (1/2 peak): |
17° |
Housing color: |
Black |
Display type: |
4 digits 7-segment LED display |
Dimensions: |
Length: 59 cm Depth: 6,5 cm Height: 10 cm |
Weight: |
1,81 kg |
